SONIX SN32F264 - Pin Assignment

SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 14 Version 1.5
1.4 PIN ASSIGNMENT
SN32F268F (LQFP 48 pins)
VSS
D-/PSDATA
D+/PSCLK
VREG33
VDD
VDDIO1
P1.0
P1.1/CT16B0_CAP0
P1.2/SEL0
P1.3/SCK0
P1.4/MISO0
P1.5/MOSI0
48
47
46
45
44
43
42
41
40
39
38
37
P2.0
1
●
36
P2.10
P2.1
2
35
P2.9
P2.2
3
34
P2.8
P0.0/CT16B1_PWM0/CLKOUT
4
33
P2.7
P0.1/CT16B1_PWM1
5
32
P2.6
P0.2/CT16B1_PWM2
6
SN32F268F
31
P2.5
P0.3/CT16B1_PWM3
7
30
P2.4
P0.4/CT16B1_PWM4/SCL0
8
29
P2.3
P0.5/CT16B1_PWM5/SDA0
9
28
P3.8/RESET/CT16B1_PWM22
P0.6/CT16B1_PWM6
10
27
P3.7/SWDIO
P0.7/CT16B1_PWM7
11
26
P3.6/SWCLK
P0.8/CT16B1_PWM8
12
25
P3.5 CT16B1_PWM21
13
14
15
16
17
18
19
20
21
22
23
24
P0.9/CT16B1_PWM9
P0.10/CT16B1_PWM10
P0.11/CT16B1_PWM11
P0.12/CT16B1_PWM12
P0.13/CT16B1_PWM13
P0.14/CT16B1_PWM14
P0.15/CT16B1_PWM15
P3.0/CT16B1_PWM16
P3.1/CT16B1_PWM17
P3.2/CT16B1_PWM18
P3.3/CT16B1_PWM19
P3.4
