SONIX SN32F264 - Ct16 Bn External Match Control Register 2(Ct16 Bn_Emc2)(N=1)

SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 74 Version 1.5
10: CT16Bn_PWM7 pin is HIGH.
11: Toggle CT16Bn_PWM7 pin.
13:12
EMC6[1:0]
Determines the functionality of CT16Bn_PWM6.
00: Do Nothing.
01: CT16Bn_PWM6 pin is LOW.
10: CT16Bn_PWM6 pin is HIGH.
11: Toggle CT16Bn_PWM6 pin.
R/W
0
11:10
EMC5[1:0]
Determines the functionality of CT16Bn_PWM5.
00: Do Nothing.
01: CT16Bn_PWM5 pin is LOW.
10: CT16Bn_PWM5 pin is HIGH.
11: Toggle CT16Bn_PWM5 pin.
R/W
0
9:8
EMC4[1:0]
Determines the functionality of CT16Bn_PWM4.
00: Do Nothing.
01: CT16Bn_PWM4 pin is LOW.
10: CT16Bn_PWM4 pin is HIGH.
11: Toggle CT16Bn_PWM4 pin.
R/W
0
7:6
EMC3[1:0]
Determines the functionality of CT16Bn_PWM3.
00: Do Nothing.
01: CT16Bn_PWM3 pin is LOW.
10: CT16Bn_PWM3 pin is HIGH.
11: Toggle CT16Bn_PWM3 pin.
R/W
0
5:4
EMC2[1:0]
Determines the functionality of CT16Bn_PWM2.
00: Do Nothing.
01: CT16Bn_PWM2 pin is LOW.
10: CT16Bn_PWM2 pin is HIGH.
11: Toggle CT16Bn_PWM2 pin.
R/W
0
3:2
EMC1[1:0]
Determines the functionality of CT16Bn_PWM1.
00: Do Nothing.
01: CT16Bn_PWM1 pin is LOW
10: CT16Bn_PWM1 pin is HIGH…
11: Toggle CT16Bn_PWM1.
R/W
0
1:0
EMC0[1:0]
Determines the functionality of CT16Bn_PWM0.
00: Do Nothing.
01: CT16Bn_PWM0 pin is LOW.
10: CT16Bn_PWM0 pin is HIGH.
11: Toggle CT16Bn_PWM0.
R/W
0
6.7.16 CT16Bn External Match Control register 2(CT16Bn_EMC2)(n=1)
Address Offset: 0x90
The External Match Control register 2 provides control of CT16Bn_PWM [22:0]. If the match outputs are configured as
PWM output, the function of the external match registers is determined by the PWM rules.
Bit
Name
Description
Attribute
Reset
31:13
Reserved
R
0
13:12
EMC22[1:0]
Determines the functionality of CT16Bn_PWM22.
00: Do Nothing.
01: CT16Bn_PWM22 pin is LOW.
10: CT16Bn_PWM22 pin is HIGH.
11: Toggle CT16Bn_PWM22 pin.
R/W
0
11:10
EMC21[1:0]
Determines the functionality of CT16Bn_PWM21.
00: Do Nothing.
01: CT16Bn_PWM21 pin is LOW.
10: CT16Bn_PWM21 pin is HIGH.
11: Toggle CT16Bn_PWM21 pin.
R/W
0
9:8
Reserved
R
0
7:6
EMC19[1:0]
Determines the functionality of CT16Bn_PWM19.
00: Do Nothing.
01: CT16Bn_PWM19 pin is LOW.
10: CT16Bn_PWM19 pin is HIGH.
11: Toggle CT16Bn_PWM19 pin.
R/W
0
