Figure 10.3: B/CDI/DPI/TDI menus in PW/CW duplex mode (PW/CW spectral display is inactive)
10.1.2 2D Refresh
2D REFRESH
Note that this function is available only for PW-duplex mode and B+CW
mode.
Set this item to On to enable the real-time 2D image display when spectral display
is active.
When 2D Refresh is set to Off, the 2D image is frozen once the spectral display is
active.
