SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
• use the LEFT/RIGHT keys to adjust the output power of the transducer.
Remark:
• The acoustic output power in the CW mode is displayed on the screen at the
Spectral Doppler Image Info area (PWR).
10.3.6 Dynamic Range (DYN)
DYN
Refer to Section 10.2.13.
10.3.7 Chroma
CHROMA
Refer to Section 10.2.14.
10.3.8 Video Invert
VIDEO INVERT
Refer to Section 10.2.15.
10.3.9 Display Format
DISPLAY FORMAT
Refer to Section 10.1.3.
10.3.10 Pulse Repetition Frequency (PRF)
Refer to Section 10.2.3.
10.3.11 Wall Filter (WF)
WF
Refer to Section 10.2.4.
10.4 Spectral Doppler Cine Mode Operation
Either in PW or CW mode, if the spectral display is not active,
press the FREEZE actually freezes the 2D image.
When the spectral display is active, press the FREEZE key to acti-
vate the spectral Doppler cine mode.
P/N: 4701-0061-01B
10-10
