Page #91 background image
SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
PRF 3.0
WF 185
GN 20
PWR 70
FRQ 5.1
ECG
PERSIST
C MAP
POWER %
BASELINE
B REJECT
FREQUENCY
LTRT
LINE DENSITY
50
1
70
0
255
5.1
Low
FLOW INVERT Off
SEC.WIDTH
SEC.POS
C MAP 1
B REJECT 255
FLOW INVERT Off
LOOP SPEED
START
|
END
|
FRAME BY FRAME
....
Figure 8.2: TDI cine mode
menu
Cine Mode Operation
Move the trackball fast forward to start playing the
cine loop. Touch the trackball to stop the play-
back.
Press the MENU key and the cine mode menu
(right) will appear at the context menu area (refer
to Figure 2.2).
More cine mode operations are introduced in the following subsections.
8.4.1 C Map
C MAP
Refer to Section 8.3.7.
8.4.2 B Reject
B REJECT
Refer to Section 8.3.11.
8.4.3 Flow Invert
FLOW INVERT
Refer to Section 8.3.14.
8.4.4 Cine Playback
LOOP SPEED
START
END
FRAME BY FRAME
Refer to Section 5.4.6.
P/N: 4701-0061-01B
8-7
