5.1 Starting B Mode
Click the application icon at the preparation mode (EXAM screen) to start
a real time scan. The system enters B mode automatically. To remove
any additional modes (PW/CW/CFM/DPI/M), press the B mode key.
Figure 5.1: B mode
5.2 B Mode Image Information
FPS 13
D/G
GN
I/P
PWR
FRQ
D
160/2
47
5/30
80
3-5.2
16.5cm
B mode image information (right) is shown on the top left
corner of the screen (also refer to Figure 2.2). It shows
some parameters important for the diagnosis. The table
below shows the meaning of the items listed in the 2D Im-
age Info area.
