Sonoscape SSI-6000

SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
8.3.15 Line Density . . . . . . . . . . . . . . . . . . . . . . . . 8-6
8.4 Cine Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . 8-6
8.4.1 C Map . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
8.4.2 B Reject . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
8.4.3 Flow Invert . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
8.4.4 Cine Playback . . . . . . . . . . . . . . . . . . . . . . . 8-7
8.1 Starting TDI Mode
Press the T key on the alphanumeric keyboard to activate the TDI mode. The TDI
sample box appears in the active 2D image.
Press the B key to deactivate the TDI mode, the system enters the B mode.
8.2 TDI Image Information
PRF 1.0
WF 75
GN 20
PWR 70
FRQ 2.6
C/P 1/60
The color image information for the TDI mode ultrasound
is displayed at the Color Image Info area (refer to Figure
2.2 for the location).
The meaning for the items shown in the info area are ex-
plained in the table below.
PRF pulse repetition frequency
WF wall filter value
GN Doppler gain, D gain
C/P Color Map setting / persistence value
PWR acoustic output power (%)
FRQ transmitted frequency (MHz)
8.3 TDI Mode Operation
The TDI mode operation for the current ultrasound image is independent of the
display format (single, dual or quad). TDI mode parameters and settings can be
adjusted through the TDI mode menu or directly using the knobs / flip switches.
8.3.1 TDI Menu
P/N: 4701-0061-01B
8-2
