Sonoscape SSI-6000 User Manual

SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
• Use the trackball to change the M cursor position.
• Use the LEFT/RIGHT keys to change the angle of the M mode cursor.
• If multiple M cursors are present, press the SET key to select the next M cursor.
The currently selected M cursor is highlighted in cyan.
 Remarks:
• The STEER M function is primarily for cardiology application and may be dis-
abled in other application modes.
• If multiple M cursors are present, only the last selected M cursor (in cyan) will
be active upon activating the CDI+M/TDI+M duplex mode.
9.3 M Mode Operation, M Trace Active
FOCAL SPAN ↔
ECG →
DYN
FOCAL NUMBER 4
GSC
PERSIST
TISSUE ACOUSTIC
CHROMA
SEC.WIDTH
SEC.POS
LINE DENSITY
BIOPSY
COMPOUND
FREQUENCY
LT↔RT
ADAPT.IM FUSION
POWER %
1540
160
30
1
2
↔
↔
Off
On
High
3.0 - 5
↔
80
5
TRAPEZOID Off
uScan On
GSC 2
CHROMA 1
LT↔RT
↔
PLAY/STOP
|→
CINE REVIEW
↔
LOOP SPEED
↔
START
|←
END
→|
FRAME BY FRAME
....
FOCAL SPAN ↔
ECG →
DYN
FOCAL NUMBER 4
GSC
PERSIST
CHROMA
SEC.WIDTH
SEC.POS
LINE DENSITY
FREQUENCY
LT↔RT
POWER %
160
30
1
2
↔
↔
High
3.0 - 5
↔
80
STEER M Off
B MODE
DISPLAY FORMAT V1/2
UP|DOWN Off
M MODE
(inactive)
M MODE
(active)
SWEEP SPEED 4
POWER % 70
CHROMA 1
VIDEO INVERT Off
M PROCESS Peak
ECG →
DISPLAY FORMAT V1/2
M MODE
(updated,
frozen)
CHROMA 1
VIDEO INVERT Off
DISPLAY FORMAT V1/2
START
|←
END
→|
FRAME BY FRAME
....
MPR PEK
SR 4
GN 200
PWR 85
Press the UPDATE key to let the M mode trace up-
date. Some M mode parameters (right) are displayed
at the M Mode Info area.
Press the UPDATE key again to stop updating the M
mode trace.
SWEEP SPEED 4
POWER % 70
CHROMA 1
VIDEO INVERT Off
M PROCESS Peak
ECG →
DISPLAY FORMAT V1/2
Press the MENU key to activate the M
mode menu (right).
The following subsections provide in-
structions for the M mode operation
while the M trace is active.
9.3.1 M Gain
Only when the M trace is updating can the M mode gain be changed. Note that
the M gain is different from the B mode (2D) gain.
The M gain controls the overall brightness of the M trace, it determines how much
the amplification of the echoes is.
Turn the GAIN knob to adjust the M gain.
 Remark:
• The M gain value is shown at the M Mode Image Info area (the GN).
9.3.2 Sweep Speed
SWEEP SPEED
Use this function to adjust the speed of sweeping in the M mode. The larger the
sweep speed is set, the faster the M trace is updating.
To adjust the sweep speed, highlight SWEEP SPEED in the M mode menu, and press
the LEFT/RIGHT key to reduce/increase its value.
P/N: 4701-0061-01B
9-3
