Sonoscape SSI-6000

SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Chapter 11
3D Mode
∗
The 3D imaging is part of the 4D package which is optional and can be
installed upon the user request.
3D ultrasound allows the user to see width, height and depth of the anatomical
structure. In this case, the echoes are processed by a sophisticated computer
program resulting in a reconstructed three dimensional volume image of internal
organs or fetus.
Since this 3D image is generated after 2D information is collected, it is not real
time. For real time 3D, or 4D, refer to Chapter 12.
Contents
11.1 Starting 3D Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
11.2 3D Mode Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
11.3 3D Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
11.3.1 Display Format . . . . . . . . . . . . . . . . . . . . . . . 11-3
11.3.2 Rotate and Zoom . . . . . . . . . . . . . . . . . . . . . 11-3
11.3.3 Clear & Restore ROI . . . . . . . . . . . . . . . . . . . . 11-4
11.3.4 Crop . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4
11.3.5 ROI Box Adjustment . . . . . . . . . . . . . . . . . . . . 11-4
11.3.6 Render Mode . . . . . . . . . . . . . . . . . . . . . . . 11-4
11.3.7 Auto Rotate . . . . . . . . . . . . . . . . . . . . . . . . 11-4
11.3.8 Trace Cut . . . . . . . . . . . . . . . . . . . . . . . . . 11-5
11.3.9 Clip Plane . . . . . . . . . . . . . . . . . . . . . . . . . 11-6
11.3.10 Opacity Setting . . . . . . . . . . . . . . . . . . . . . . 11-6
11.3.11 Multi-Slice . . . . . . . . . . . . . . . . . . . . . . . . . 11-6
11.3.12 Color Map . . . . . . . . . . . . . . . . . . . . . . . . . 11-6
11.3.13 Scan Method . . . . . . . . . . . . . . . . . . . . . . . 11-6
11.3.14 Z Scale (For Scan Method = Lin) . . . . . . . . . . . . . 11-6
11.3.15 Z Angle (For Scan Method = Sec) . . . . . . . . . . . . . 11-7
P/N: 4701-0061-01B
11-1
