Sonoscape SSI-6000

SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Chapter 9
M Mode
M mode can only be used with the B, CDI, or TDI mode to form the B+M, CDI+M,
TDI+M duplex mode.
Contents
9.1 Starting M Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
9.2 M Mode Operation, M Trace Inactive . . . . . . . . . . . . . . . . 9-2
9.2.1 Adjust M Mode Cursor Line . . . . . . . . . . . . . . . . 9-2
9.3 M Mode Operation, M Trace Active . . . . . . . . . . . . . . . . . 9-3
9.3.1 M Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
9.3.2 Sweep Speed . . . . . . . . . . . . . . . . . . . . . . . 9-3
9.3.3 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9.3.4 Chroma . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9.3.5 Video Invert . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9.3.6 M Process . . . . . . . . . . . . . . . . . . . . . . . . . 9-4
9.3.7 Display Format . . . . . . . . . . . . . . . . . . . . . . . 9-5
9.4 Cine Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . 9-5
9.1 Starting M Mode
Press the M mode key during the real time scan with B/CDI/TDI mode
to activate the B+M/CDI+M/TDI+M duplex mode.
Only phased array probes (2P1) support CDI+M and TDI+M modes.
Press the M mode key again to deactivate the M mode.
Initially the M mode cursor line (a straight line across the ultrasound image) is
inserted at the center of the 2D ultrasound image. The M mode trace (Figure 9.1)
will not be active until the UPDATE key is pressed.
P/N: 4701-0061-01B
9-1
