SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Model Description Intended Applications
L741 Linear Array, 5.0-
10.0 MHz
Small Organ, Musculo-skeletal (Conventional &
Superficial), Peripheral vessel
L742 Linear Array, 5.0-
12.0 MHz
Small Organ, Musculo-skeletal(Conventional &
Superficial), Peripheral vessel
L743 Linear Array, 5.0-
10.0 MHz
Small Organ, Musculo-skeletal(Conventional &
Superficial), Peripheral vessel
C344 Curved Array, 2.0-
5.0 MHz
Fetal , Abdominal, Ob/GYN
C362 Curved Array, 2.0-
6.0 MHz
Fetal , Abdominal, Ob/GYN
VC6-2 Curved Array, 2.0-
6.0 MHz
Fetal , Abdominal, Ob/GYN
2P1 Phased Array, 2.0-
4.0 MHz
Abdominal, Neonatal Cephalic, Adult Cephalic,
Cardiac Adult, Cardiac Pediatric
5P1 Phased Array, 3.0-
7.0 MHz
Pediatric, Neonatal Cephalic, Cardiac Pediatric
6V1 Micro-curved Array,
4.0-8.0 MHz
Transrectal, Transvaginal
6V3 Micro-curved Array,
5.0-9.0 MHz
Transrectal, Transvaginal
EC9-5 Micro-curved Array,
5.0-9.0 MHz
Transrectal, Transvaginal
C611 Micro-curved Array,
4.0-8.0 MHz
Abdominal, Pediatric, Neonatal Cephalic, Cardiac
Pediatric
Table 13.1: Transducer list
13.1.2 Acoustic Output
The acoustic output powers for the supported transducers are listed in the Acous-
tic Output Tables in the companion CD-ROM of this manual.
13.2 Environmental Requirements
The transducers should be used with that the following environmental requirements
has been satisfied.
Operation Storage and transport
Relative humidity 30%∼75%, no condensation 20%∼90%, no condensation
Ambient tempera-
ture
10°C∼40°C -20°C∼55°C
Barometric pres-
sure
700hPa∼1060hPa 700hPa∼1060hPa
13.3 Preparation and Usage of the Probe
13.3.1 Inspection
After each use, or before first use or after long-time storage of the probe, the probe
must be examined for any damages listed in the table below. Stop using the probe
P/N: 4701-0061-01B
13-2
