Sonoscape SSI-6000

SSI-6000/SSI-5800/SSI-5500/SSI-5500BW
Digital Color Doppler Ultrasound System
Chapter 8
TDI Mode (Tissue Doppler
Imaging)
Tissue Doppler Imaging (TDI) captures the wall motion of vessels and creates a
color image displaying the tissue motion. TDI is a cardiography technique, so it
can only be used in cardiology application modes.
Like conventional Doppler mode, TDI also uses Doppler principle. However, in TDI
mode high amplitude (high intensity), low frequency tissue motion is quantified.
In contrast, in the conventional Doppler mode low amplitude (low intensity), high
frequency blood motion is quantified.
Attention!
Only phased array probes (2P1) are TDI capable.
Contents
8.1 Starting TDI Mode . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.2 TDI Image Information . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.3 TDI Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.3.1 TDI Menu . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8.3.2 Adjust TDI Sample Box . . . . . . . . . . . . . . . . . . 8-3
8.3.3 Pulse Repetition Frequency . . . . . . . . . . . . . . . . 8-3
8.3.4 Wall Filter . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
8.3.5 TDI Gain . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8.3.6 Persistence . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8.3.7 Color Map . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8.3.8 TDI Power . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8.3.9 Baseline . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
8.3.10 Sector Width and Position . . . . . . . . . . . . . . . . . 8-5
8.3.11 B Reject . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
8.3.12 TDI Frequency . . . . . . . . . . . . . . . . . . . . . . . 8-5
8.3.13 Image Orientation (Left/Right) . . . . . . . . . . . . . . . 8-6
8.3.14 Flow Invert . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
P/N: 4701-0061-01B
8-1
