11.3.3 Clear & Restore ROI
CLEAR ROI
Highlight this item and press the SET key over it to clear the ROI region. The result
is, in 3D and 2D images, the regions inside the ROI boxes are removed.
RESTORE ROI
Press this item to restore the display of the region removed by CLEAR ROI previ-
ously.
Note: to adjust the ROI boxes, see Section 11.3.5.
11.3.4 Crop
CROP
Instead of removing the region inside the ROI box, as what CLEAR ROI does, this
function crops the display to the ROI box.
Note: to adjust the ROI boxes, see Section 11.3.5.
11.3.5 ROI Box Adjustment
ROI MODE
This item should be set to On in order to adjust the ROI boxes.
HIDE ROI
Note that HIDE ROI option is automatically turned off upon enabling ROI MODE.
Instructions for adjusting the ROI boxes:
1. Press the UPDATE key over a 2D image to select the image. The frame box of the
selected image will be highlighted upon the selection.
2. Move the trackball to move the ROI box position.
3. Press the SET key; move the trackball to resize the ROI box.
4. Press the SET key again to enable moving the ROI box position.
5. Press the UPDATE key to deselect the image. Move the cursor over another image and
press the SET key to select it.
11.3.6 Render Mode
RENDER MODE
Three render modes are available: Volume Rendering (Vol), X-ray, Maximum In-
tensity Projection (MaxIP).
11.3.7 Auto Rotate
AUTO ROTATE
Turn on this function to activate the auto-rotation of the display of the 3D structure.
This function is normally used for demonstration purpose.
The maximum angle of rotation can be set to 
◦
, 
◦
, 
◦
, 
◦
, or 
◦
. The
display of the 3D structure rotates continuously (first clockwise and then counter-
clockwise) from 
◦
to this maximum angle.
