Sony MK7807V1 - Analog

Specifications
Control
REMOTE 1:
Standard S-BUS
Connector type: BNC type (3)
Protocol: S-BUS
Transfer speed: 312 kb/s/1250 kb/s
REMOTE 2:
RS-422A
Connector type: D-sub 9-pin female (2)
Protocol: Sony CART+ protocol
Transfer speed: 38.4 kb/s
REMOTE 3:
RS-232C
Connector type: D-sub 9-pin male (1)
Protocol: Terminal/ISR/Data Backup
Transfer speed: 9600 b/s/38.4 kb/s
REMOTE 4:
Monitor S-BUS
Connector type: BNC (1)
Protocol: S-BUS
Transfer speed: 312 kb/s
Video connectors:
BNC type
Inputs return loss:
More than 40 dB DC to 5 MHz
Clamping:
Pedestal clamping or DC coupled
Frequency response:
100 kHz to 10 MHz, +/-0.15 dB
10 MHz to 30 MHz, +0.5/-1.0 dB,
DG:
Less than 0.1%
DP:
Less than 0.1 °
Signal to noise ratio:
More than 73 dB at 5 MHz
Crosstalk:
Less than -60 dB at 5 MHz
Analog audio
Inputs connector:
D-sub 25-pin w/stereo 4 channels by 1
connector
Inputs impedance:
20 kΩ /600 Ω internally selectable
Max inputs level:
+24 dBm, balanced
Converter:
ADC 48 kHz/20 bits, Linear, AES/EBU
digital audio
Frequency response:
20 Hz to 20 kHz, +0.2/-0.3
Distortion:
0.05% or less (1 kHz, reference level,
30 kHz low pass filter)
Signal to noise ratio:
More than 90 dB (30 kHz low pass filter)
Crosstalk:
Less than -90 dB to 15 kHz
Converter:
DAC 48 kHz/20 bits
Maximum output level:
+24 dBm into 600 Ω balanced.
Output impedance:
Approx. 20 Ω
Output connector:
D-sub 25-pin w/stereo 4 channels by 1
connector
AES / EBU digital audio
Inputs connector:
BNC type
Signal standards:
AES/EBU specification
75 Ω, unbalanced
SMPTE276M-1995
Television-Transmission of AES/EBU
digital audio signals over coaxial cable
Inputs signal level:
1 Vp-p
Max inputs cable length:
600 m max. (When using a Belden
8281, Fujikura 5C2V or equivalent
coaxial cable)
Reference:
Word sync and analog video signal
Outputs connector:
BNC type
General
Power requirements:
100 to 240 V AC, 50/60 Hz
Power consumption:
600 VA max.
Dimensions (W x H x D):
424 x 620 x 550 mm
(16 3/4 x 24 1/2 x 21 3/4 inches)
Mass:
Approx. 40 kg (88.18 lb)
Service parts: Extension board EX-717 (Part No.
A-8323-641-A), Extension board EX-681
(A-8323-641), Maintenance manual Part II,
Protocol Manual
