Applicable Models
PFV-L10 Interface unit
Supplied Accessories
EX-731 Extension Board (Part
No.A-8322-598-A) (1)
The BKPF-L603 SDI distribution board accepts a 525/625
component serial digital or NTSC/PAL composite serial
digital video signal and distributes it to eight outputs. The
output cable length can be up to 200 m (Belden 8281,
Fujikura 5C2V or equivalent cable).
Features
* 525/625 component serial digital or NTSC/PAL
composite serial digital video input * Eight equalized and
re-clocked distribution outputs * High quality 10-bit signal
processing * Automatic equalization for output cable
length of up to 200m (with Belden 8281, Fujikura 5C2V or
equivalent cable)
The BKPF-L Series function boards install in the PFV-L Series Interface Units
in any combination with other BKPF-L Series function boards.
73
Interface Processor L Series
Interface Processor L Series
BKPF-L603 SDI Distribution Board
Rear Panel
