Routing Switcher Reference Guide
Routing Switcher Options
Routing switcher
Cascade set
Backup CPU Backup Power
Monitoring output Input
type boards Supply Units
HDS-X5800 Standard Standard Standard
HKS-5810M(HD/SD)
HKS-5810SD(SD)
HDS-X3700 Standard Standard Standard
HKDS-X3014(HD/SD)
HDS-X3600 Standard Standard Standard
HKDS-X3011(SD)
HDS-X3400 Standard
HKSP-061M
BKPF-300
BVS-V3232 BKDS-RS1690 BKDS-PV3291
BKPF-301
BVS-A3232 BKDS-RS1690 BKDS-PV3291
BKPF-351
BKPF-350
DVS-128 Standard Standard
BKDS-AV10(Analog video)
BKDS-AA10(Analog audio)
DVS-RS1616 BKDS-RS1620 BKDS-RS1690 BKDS-RS1691
DVS-TC3232 BKDS-RS1620 BKDS-RS1690 BKDS-RS1691
HKSP-R80 HKSP-R81
BKPF-R70A BKPF-R70A
