Sony MK7807V1 - Analog

Specifications
Inputs/outputs
Serial digital input:
SDI IN connector (BNC type) (1),
0.8 Vp-p, 75 Ω, 4:2:2 component serial
digital signal, conforming to
SMPTE-259M-C, 270 Mb/s
Reference input:
REF IN connector (BNC type) (1), 0.3
Vp-p 610%, 75 Ω, black burst signal
Digital input return loss:
15 dB or more (5 MHz to 270 MHz)
Serial digital output:
Active loop-through output connector
(BNC type) (1),
0.8 Vp-p, 75 Ω, 4:2:2 component serial
digital signal, conforming to
SMPTE-259M-C, 270 Mb/s
Analog video outputs:
ANALOG OUT connectors (BNC type)
(4),
NTSC/PAL composite analog video
signal, 1.0 Vp-p, 75 Ω
Reference output:
Passive loop-through output connector
(BNC type) (1),
0.3 Vp-p 610%, 75 Ω, black burst
signal
Digital output return loss:
15 dB or more (5 MHz to 270 MHz)
Cable length:
200 m max. (with Belden 8281, Fujikura
5C2V or equivalent coaxial cable)
Channel coding:
Scrambled NRZI
Video characteristics
Sampling frequency:
27 MHz
Quantization:
10 bits
Band width:
5.75 MHz
DG:
1% or less
DP:
Within 1 °
K factor (2T pulse):
1% or less
Signal-to-noise ratio:
60 dB or more (using Flat Field)
Y/C delay:
610 ns or less
Processing delay:
4 µs (NTSC)/7.5 µ (PAL)
Phase adjustment range
Line:
-2 H, -1 H, 60 H, +1 H
Input lock mode:
0.1 to 8.5 µs (NTSC), 0.1 to 7.0 µs
(PAL)
External REF mode:
-4.2 to +4.2 µs (35 ns steps NTSC),
-3.5 to +3.5 µs (28 ns steps PAL),
Test signal 75% color bars with 100%
white
General
Power requirement:
+5 V DC: 1.2 A (supplied from PFV-L
Series Interface Unit)
Operating temperature:
5 to 40 °C (41 to 104 °F)
Storage temperature:
-20 to 60 °C (-4 to 140 °F)
Operating humidity:
10 to 90% (no condensation)
Dimensions
Board (H x W):
77 x 267 mm
(3 1/8 x 10 3/4 inches)
Connector panel (H x W):
33 x 85 mm
(3 3/8 x 1 5/16 inches)
Mass
Board:
Approx. 150 g (5 oz)
Connector panel:
Approx. 100 g (4 oz)
Service part: Maintenance manual
