SpeakerCraft MZC-88 Installation Instructions

Page 110 MZC-88 Installation Instructions
Control Sections
Contact Closures (Dry) 2A, 30 VAC/DC max
Phone Page In - Voltage/Impedance Audio Line Level, > 22k Ohm
Video Page In 1.0 V p-p, 75 Ohm
Common IR Out - HI (High Power) 9 V Active High, 82 Ohms
- LO (Emitter Power) 9 V Active High, 670 Ohms
Zone IR Outs - Voltage/Impedance 9.2 V Active High, 620 Ohms
Source IR Outs (and Loop) - Voltage/Impedance 11.5 V Active High, 390 Ohms
Common Status Out (0 to 12 V DC) 9.5 V @ 100 mA
Status IN (3-8) 4.5 to 30 V DC 2 mA @ 12 V
General
Power Consumption
No signal (idle) 75 Watts
At
1
⁄8 Rated Power (6.25 Watts/Channel) 275 Watts
Line Ratings 120 VAC, 3A
Rear Panel Fuse T6.3AL 250V
Dimensions
17” (432mm) W x *5-
1
⁄4” (133mm) x 14-
3
⁄4” (375mm)D
*5-
3
⁄4” (146mm) H, including feet
Weight
31.5 lbs (14.3 kg)
