SpeakerCraft MZC-88 Installation Instructions

MZC-88 Installation Instructions Page 39
FUSE 10 AMP
AC 120V 60HZ
Power
Consumption
830 Wa tt s
SpeakerCra ft
®
Riverside, California, USA
SERIAL NUMBER
Model BB1235 12-Channel Amplifier
3-30VAC/DC
TRIGGER
INPUT
12V
CONTROL
OUTPUT
AUDIO
SENSE
3-30V
AC/DC
TRIGGER
INPUT
CONSTANT
BU S
INPUT
LEVE L
BUS• AU X•LINE
BRIDG E
OFF ON
BRIDG E
OFF ON
BRIDG E
OFF ON
BRIDG E
OFF ON
BRIDG E
OFF ON
BRIDG E
OFF ON
BRIDGED
R R+L L
LINE
IN
LEVE L
BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE BUS• AU X•LINE
BUS• AU X•LINE BUS• AU X•LINE
R R+L L
LEVE L
R R+L L
LINE
IN
LEVE L
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
R R+L L
LINE
IN
LL
RR
LL
RR
BU S
OUTPUT
AU X
INPUT
AU X
OUTPUT
+ +
----
+ +
----
+ +
----
+ +
----
+ +
----
+ +
----
LINE INPUT S
+ BRIDGED -- + BRIDGED --+ BRIDGED -- + BRIDGED --+ BRIDGED -- + BRIDGED --
SPEAKER OUTPUT S
InstaLLock™ Plugs
CHANNELS 1
-
8 CHANNELS 9
-
12
CHANNEL 1 CHANNEL 2
CHANNEL 1 CHANNEL 2
CHANNEL 3 CHANNEL 4
CHANNEL 3 CHANNEL 4
CHANNEL 5 CHANNEL 6
CHANNEL 5 CHANNEL 6
CHANNEL 7 CHANNEL 8
CHANNEL 7 CHANNEL 8
CHANNEL 9 CHANNEL 10
CHANNEL 9 CHANNEL 10
CHANNEL 11 CHANNEL 12
CHANNEL 11 CHANNEL 12
BRIDGED BRIDGED BRIDGED BRIDGED BRIDGED
8Ω 4Ω
8Ω 4Ω
8Ω 4Ω
8Ω 4Ω
8Ω 4Ω
8Ω 4Ω
LINE
IN
LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL
MZC-88
BB1235
PS-1.0 200mA Power Supply
To Unswitched Outlet
Black Wire (GND)
White Striped
Wire (+12V)
Contact Closure Pair 1
RCA-RCA
Stereo
Patch Cable
Zone L&R Line-Level
Audio Pre-Out
28-12AWG
Two-Conductor
Stranded Wire
12 Volt
Control Input
12 Channel Amplifier
L&R Line-Level
Audio Bus Input
Sub-Zone
Speakers
SpeakerCraft
AIM8 Four
Sub-Zone
L&R Speaker Level
Output
18-14AWG
Two-Conductor
Speaker Wire
Zone VC/NVC Switch
Sub-Zone
Volume Control
SpeakerCraft
VST60
Figure 21
Adding a 12-Channel Amplifier
HIGH-POWER ALL ZONES
Another option for adding external amplification, is to connect each of the MZC-88 Zone Pre-Outs directly to the individual
line-level inputs on the SpeakerCraft DBB 12100, 100 Watts by twelve channel amplifier. This option maintains individual
zone control via EZ-Pads, as in a normal MZC-88 system, but now cranks up the audio power to a massive 100 Watts per
channel in up to six zones!
1. Using a quality stereo RCA to RCA cable, connect the Zone L & R Pre-Outs to the individual line level inputs on the
DBB12100. (The DBB12100 inputs are labeled 1-12, so Zone 1 would use inputs 1&2, Zone 2 would use 3&4, etc.)
2. Set the VC/NVC switch on the MZC-88 Rear Panel to VC (variable) so the zone keypad can be used to adjust volume.
3. Connect zone speakers to the DBB 12100 Speaker Terminals in the same pairings as the Pre-amp connections.
4. Switch the BUS/AUX/LINE Input select switch on the DBB12100 to LINE for all channels connected to MZC-88 Pre-outs.
5. Connect a Trigger Input to the DBB 12100 for Power ON/OFF as shown in Figure 21.
