MZC-88 Installation Instructions Page 73
6. TREBLE can now be programmed in a similar manner. Left click the TREBLE button, then Tier 1 under Button
Properties.
7. Right click the TREBLE button, then left click Switch to Tier 3 on the Insert Tier Command line of the pop-up. This will
cause the first press of the TREBLE key to point to Tier 3 commands on the TREBLE and UP/DOWN keys.
8. Left click Tier 2, right click TREBLE and then select Switch to Tier 3 from the Insert Tier Command line. This will cause
a return to TREBLE action after pressing the BASS key.
9. Left click Tier 3 under Button Properties, then double left click Zone 8 Treble Flat from the MZC-88 CMDs Tab/Tone
Commands list. This will cause the 2
nd
press of the TREBLE key to execute the Treble Flat function. This completes the
TREBLE key programming.
10. The next step is to program the UP/DOWN keys using the FKP-1.0 cursor UP/DOWN buttons for Bass and Treble up/down
action. (The Volume UP/Down buttons on the MKP-8.1 or UP/DOWN buttons on the NKP-1.0 can also be used.)
11. Left click the UP key then Tier 2 under Button Properties.
12. Double left click Zone 8 Bass Up from the MZC-88 CMDs Tab/Tone Commands list. This places the Zone 8 Bass Up
command on Tier 2 of the UP key. This will allow the UP key to increase Bass Boost after 1
st
pressing the BASS key.
Figure 65
Placing Zone 1 Bass Flat Command
13. Repeat steps 11 & 12, but this time place Zone 8 Bass Down on Tier 2 of the DOWN key. This will allow the DOWN key
to decrease Bass Boost after 1
st
pressing the BASS key.
14. Left click the UP key then Tier 3 under Button Properties.
15. Double left click Zone 8 Treble Up from the Tone Commands list. This allows the UP key to increase Treble Boost after
1
st
pressing the TREBLE key.
16. Repeat steps 15 & 16, but this time place Zone 8 Treble Down on Tier 3 of the DOWN key. This allows the DOWN key
to decrease Treble Boost after 1
st
pressing the TREBLE key.
17. Right click the BASS key and left click Punch Key’s Commands on the pop-up. Repeat this for the TREBLE and UP/
DOWN keys as well. This will ensure that the Bass and Treble actions will apply to all sources in the Zone.
In addition, this Zone can be cloned to all the other Zones to save programming time. Refer to “Cloning and…” section
and Figure 35 for details.
18. This completes the Bass and Treble keys programming and it accomplishes the following:
BASS: 1
st
press changes the UP/DOWN keys to Bass Up/Down. 2
nd
press = Bass Flat.
TREBLE: 1
st
press changes the UP/DOWN keys to Treble Up/Down. 2
nd
press = Treble Flat.
NOTE: Tier 1 on the UP/DOWN keys is still open and can be used for other functions, such as Random or Repeat
commands for a CD source.
Other types of Tier programming can be accomplished using the same basic procedures as above.
