Luminex Users Guide
Chapter 2 Hardware
Function Sensors
On either side of the Status LCD are three touch sensitive sensors. The far left sensor turns the
Luminex On and Off.
Each sensor serves a specific purpose, or function, on the different menus. The menu bar is located
at the bottom of the tilting screen.
Touch the associated sensor, just below a function on the menu bar, to perform the action. For
example, on the Opening menu, the word Off displays above the left most sensor. Touching the
sensor for more than one second and then lifting your finger off the sensor turns the Luminex Off.
Simply touching the Off sensor, does not turn the Luminex off to prevent accidentally turning of the
writer. Another example on the Opening Menu is the sensor associated with Dict. Touch the Dict
sensor to select a job dictionary. When you touch Dict, another menu displays, listing more menu
choices related to using dictionaries. From this menu, touch the sensor below Select to display a list
of job dictionaries from which you can choose.
