STEP AS380 Series User Manual

Shanghai STEP Electric Corporation
Chapter 6 Introduction to the supporting products
144
No.
Position
Port No.
Port definition
Corresponding LED
No. 4 elevator in group control system
JP2.5
TXV4+
Communication power positive port of
No. 4 elevator in group control system
JP2.6
Void
D103
JP2.7
TXA3-
Communication signal negative port of
No. 3 elevator in group control system
JP2.8
TXA3+
Communication signal positive port of
No. 3 elevator in group control system
JP2.9
TXV3-
Communication power negative port of
No. 3 elevator in group control system
JP2.10
TXV3+
Communication power positive port of
No. 3 elevator in group control system
JP2.11
Void
D102
JP2.12
TXA2-
Communication signal negative port of
No. 2 elevator in group control system
JP2.13
TXA2+
Communication signal positive port of
No. 2 elevator in group control system
JP2.14
TXV2-
Communication power negative port of
No. 2 elevator in group control system
JP2.15
TXV2+
Communication power positive port of
No. 2 elevator in group control system
JP2.16
Void
D101
JP2.17
TXA1-
Communication signal negative port of
No. 1 elevator in group control system
JP2.18
TXA1+
Communication signal positive port of
No. 1 elevator in group control system
JP2.19
TXV1-
Communication power negative port of
No. 1 elevator in group control system
JP2.20
TXV1+
Communication power positive port of
No. 1 elevator in group control system
JP3
JP3.1
Void
D108
JP3.2
TXA4-
Communication signal negative port of
No. 8 elevator in group control system
JP3.3
TXA4+
Communication signal positive port of
No. 8 elevator in group control system
JP3.4
TXV4-
Communication power negative port of
No. 8 elevator in group control system
JP3.5
TXV4+
Communication power positive port of
No. 8 elevator in group control system
JP3.6
Void
D107
JP3.7
TXA3-
Communication signal negative port of
No. 7 elevator in group control system
