STEP AS380 Series User Manual

Instruction Manual for AS380 Series Elevator Integrated Drive Controller
Chapter 6 Introduction to the supporting products
145
No.
Position
Port No.
Port definition
Corresponding LED
JP3.8
TXA3+
Communication signal positive port of
No. 7 elevator in group control system
JP3.9
TXV3-
Communication power negative port of
No. 7 elevator in group control system
JP3.10
TXV3+
Communication power positive port of
No. 7 elevator in group control system
JP3.11
Void
D106
JP3.12
TXA2-
Communication signal negative port of
No. 6 elevator in group control system
JP3.13
TXA2+
Communication signal positive port of
No. 6 elevator in group control system
JP3.14
TXV2-
Communication power negative port of
No. 6 elevator in group control system
JP3.15
TXV2+
Communication power positive port of
No. 6 elevator in group control system
JP3.16
Void
D105
JP3.17
TXA1-
Communication signal negative port of
No. 5 elevator in group control system
JP3.18
TXA1+
Communication signal positive port of
No. 5 elevator in group control system
JP3.19
TXV1-
Communication power negative port of
No. 5 elevator in group control system
JP3-20
TXV1+
Communication power positive port of
No. 5 elevator in group control system
Note: The corresponding flashing LED indicates good communication.
Table 6.23 The definitions of the JP4 port
No.
Position
Code
Port definition
Corresponding LED
JP4
JP4.1
None
JP4.2
JP4.3
0V
Negative port 0V of +24V power supply
D100
JP4.4
+24V
+24V power input
JP4.5
Void
None
JP4.6
Void
JP4.7
+24V
VISO+, isolated positive power input
JP4.8
+24V
VISO+, isolated positive power input
JP4.9
+24V
VISO+, isolated positive power input
JP4.10
VISO-, isolated negative power input
JP4.11
Common port
Input common port, interior connected to JP4.10
JP4.12
Common port
Input common port, interior connected to JP4.10
JP4.13
X0
Reserved
D243
