Instruction Manual for AS380 Series Elevator Integrated Drive Controller
This menu display the current running speed of elevator, the unit is M/S. as above fig, the current
speed displayed is 1.75m/s
3 fault code
Fault code
Fault code serial No
The integrated unit can save up to 20 fault code. The latest fault code serial no is 00. use up or
down key to browse the these fault code. Press enter key to display the fault date, press left or
right key to check the time and floor that fault occurred. Press esc to quit.
4 System years
The above picture show: the year 2010, ―Y― is the abbreviation of year, when need to modify,
press enter button, the figure in the lowest order start to flash, use left or right button to select the
figure required for modification. The selected figure start to flash. Then use up or down button to
modify the figure ,press the enter button to confirm the modification.
5 System date
The above picture show: 8 month 12 day. ―d‖ is the abbreviation of day. When need ot modify,
press the enter button. The figure in the lowest order start to flash, use the left or right button to
select the figure required for modification. The selected figure starts to flash. Then use up or down
button to modify the figure, press the enter button to confirm the modification.
6 System time
The above figure show: 15 hour 36 minutes, T is abbreviation of time. Please note, the ―T‖
displayed in the integrated unit is always shown as that in the above figure, due to the confinement
