Litter Operation Guide
17
OPERATING IV POLES
To use the 2−Stage Permanently Attached IV pole:
NOTE
The 2−stage permanently attached IV pole is an option and may have been
installed at either the head, foot or both ends. The choice was made at the
time the unit was purchased.
1. Lift and pivot the pole from the storage position and push down until it
rests in the receptacle.
2. To raise the height of the pole, pull up on the telescoping portion (A) until
it locks into place at its fully raised position.
3. Rotate the IV hangers (B) to desired position and hang IV bags.
4. To lower the IV pole turn the latch (C) clockwise until section (A) lowers.
CAUTION
To avoid damage, the weight of the IV bags should not exceed 40 pounds.
WARNING
To avoid pinching your fingers, place the IV pole in the upright position be-
fore using the drive handle .
To use the ”Removable” IV pole:
1. Install the pole at any of the four receptacles on the bed top (located on
all four corners of the frame.)
2. To raise the height of the pole, turn knob (A) counterclockwise and pull
up on the telescoping portion (B) of the pole and raise it to the desired height.
3. Turn knob (A) clockwise to tighten the telescoping portion in place.
CAUTION
To avoid damage, the weight of the IV bags should not exceed 40 pounds.
A
C
B
