FOOT BOARD CONTROL PANEL GUIDE
1. Push repeatedly for low, medium and high settings for the siderail control panel lights. Pushing a fourth
and fifth time will turn off the siderail lights and the red nurse call light respectively (see page 18).
NOTE
The intent of the red nurse call light on the siderails is to ensure the patient immediately knows which button
to push to contact the nurse station. Turning the red light off may compromise this ability, especially in a dark-
ened room.
2. Push to lock out all bed motions. The MOTION lock icon and the “BED MOTION LOCKED” LED will light.
Push again to unlock.
3. Push to lock out Back Rest controls at both siderails. The HEAD lock icon will light. Push again to unlock.
4. Push to lock out Knee Gatch controls at both siderails. The KNEE lock icon will light. Push again to unlock.
5. Push to lock out bed height movement at both siderails. The UP/DOWN lock icon will light. Push again
to unlock.
6. Push to raise bed height.
7. Push to lower bed height.
8. Push to lower head end/raise foot end of bed (Trendelenburg position).
9. Push to lower foot end/raise head end of bed (Reverse Trendelenburg position).
CAUTION
Because individual beds may have different options, foot boards should not be moved from one bed to anoth-
er. Mixing foot boards could result in unpredictable bed operation.
