Battery Back−Up Option Head−End Enclosure

193

Black Wire Terminal

Green Wire Terminal

3002−1−801 Umbilical Cable Assembly

see page 194 for cable routing

Ground Lead

from inlet filter

2035−31−880

attach to

ground lug

3002−31−113

Umbilical Cord

Connect to power

inlet receptacle

(p/n 3002−300−880)
