Stulz EC Tower ECD 91 - 13.10 Installing the filtration box

103 © STULZ GmbH – all rights reserved EN/01.2019/G22
ec tower technical manual
13.10Installing the filtration box
In Downflow units, the filtration box is mounted on the air conditioning unit.
The filtration box is available for sizes 1 and 2.
Size 1
Size 2
160
160
26 6
201
201
600
600
1000 782
750
Dimensions

21.5
21.5
957
NOTICE
Incorrect removal of a soiled filter can cause contamination of the heat exchanger!


Installation
