Stulz EC Tower ECD 91 - 13. Options; 13.1 Overview

75 © STULZ GmbH – all rights reserved EN/01.2019/G22
ec tower technical manual
13. Options
13.1 Overview
The following accessories are available for the EC Tower, depending on the size and model version:
Option Illustration ECU/ECD 91 ECU/ECD 181/251 Item number
Section of
manual
Hot water condensate
pump
for discharging condensate
and hot waste water (>+80°C)
from the humidifier.
● ●
1200074
see „13.2“ on
page 78
Air blow-out plenum
for targeted air distribution in
the room via adjustable fins.
The blow-out noise via the
plenum is 3dB lower than an
open blow-out.
Powder-coated, anthracite gray
housing of sheet steel.
Height: 500 mm, width and
depth same as unit.
ECU 91 only 1200124
see „13.3“ on
page 87
(no illust.)
ECU 181/251 only 1200125
Blow-out plinth
for targeted air distribution in
the room via adjustable fins.
Powder-coated, anthracite gray
housing of sheet steel.
Height: 400 mm, width and
depth same as unit.
ECD 91 only 1200126
see „13.4“ on
page 88
(no illust.)
ECD 181/251 only 1200127
Raised floor stand
1000 mm
for adapting the height of the
unit to a raised floor.
Consists of a hot-dipped galva-
nized sectional steel frame.
With vibration-damping base.
ECD 91 only 1200128
see „13.5“ on
page 91
ECD 181/251 only 1200129
Raised floor stand
500 mm
for adapting the height of the
unit to a raised floor.
Consists of a hot-dipped galva-
nized sectional steel frame.
With vibration-damping base.
ECD 91 only 1200130
ECD 181/251 only 1200131
Technical data subject to change without notice; errors and omissions excepted.
●
YES
○ NO
