94 EN/01.2019/G22 © STULZ GmbH – all rights reserved
ec tower technical manual
800
125
20
113.5
29x Ø 9.5
6x 125 (=750)
88.5
977
88.5
125 125
48.5
113.5
30
20
20
5x 125 (=625)
20
13
738
125
675
56.5
31.5
38.5
13.6Installing the adapter panel for Upflow units
The adapter panel is mounted on the air conditioning unit. The adapter panel for size 1 is additionally secured
by the integrated tabs. It is not screwed to the air conditioning unit. The adapter panel is available for sizes 1
and 2 and is required for flexible canvas fittings and duct connections.
Size 2:
Size 1:
Dimensions
582
564 40
400
400
523
541
