6. Program 8 – Direct frequency request
6.1 Description
The compressor frequency of the outdoor air conditioning can be adjusted via the 010VDC signal from an
external controller.
In addition, the digital inputs can be used to switch on Cooling or Heating operating modes, and to adjust the
fan speed.
The automatic forced mode and inversion of digital outputs can also be used as an option. Control damping
can be set additionally as a special function.
The indoor air conditioning unit can be switched on or off using remote ON/OFF.
The operating, compressor, heating, or defrost signals are emitted via the digital outputs. In the event of a sys-
tem fault, an alarm signal is emitted via a digital output.
Direct frequency request is possible with the following unit series from MITSUBISHI Heavy Industries:


Direct frequency request cannot be used with KX and SX series air conditioning units.
6.2 Configuring the InterfaceIIIk for Program 8
NOTICE

S1 is not permitted.
NOTE

become effective after the system has been rebooted. An exception to this are DIP switches
S27 and S28, which govern the behavior of the 7-segment display. These DIP switches for
display behavior can also be actuated during ongoing operation.

position of the Interface III k! The ON switch setting is the position that is closest to the center
of the board.
OFF.
6.2.1 Setting Program 8 on DIP switch S1
S11 S12 S13 S14 Program Designation
OFF OFF OFF ON 8 Direct frequency request
