ec tower technical manual
No. Description
1
Junction box 1 (detail)
2
Terminal strip X1/P (junction box 1)
3
4
Terminal strip X4 (junction box 2)
5
Junction box 2 (detail)
6
PE conductor
7
8
Condensate pump power cable
9
Condensate pump
10
Live wire
11
Fault signaling contact (black core)
12
Fault signaling contact (black core)
13
PE conductor
14
Live wire
15
Control fuse F10
Procedure
1. Connect the condensate pump as per the circuit diagram.
- Connect the live wire of the condensate pump to the control fuse (F10) at terminal (2) in junction box 1.
- Connect the neutral wire of the condensate pump to terminal (X1/N5) in junction box 1.
- For size 1: Connect the PE conductor of the condensate pump to terminal (X1/PE5) in junction box 1.
2. Remove the bridge from terminals (X4/3) and (X4/4) in junction box 2.
3. Connect fault signaling contact 1 of condensate pump to terminal (X4/3) in junction box 2.
4. Connect fault signaling contact 2 of the condensate pump to terminal (X4/4) in junction box 2.
