Chapter 11 Main Logic Board and Component Replacement 11-27
FIGURE 11-15 Extracting the Main Logic Board
FIGURE 11-16 Raising the Speaker/LED Assembly
System I/O board
Main logic board
Main logic board
Speaker/power
LED assembly
extractor lever
Squeeze the two levers
at the base of the assembly,
and slide the assembly up.
