Sun Microsystems SPARC classic - System Connectors

B-1
APPENDIX
B
System Connectors
This appendix contains pinouts and illustrations of the various system connectors.
The following connectors are described.
■ Section B.1 “Attachment Unit Interface (AUI) Connector”
■ Section B.2 “Twisted-Pair Ethernet Connector”
■ Section B.3 “ISDN Terminal Endpoint Connector”
■ Section B.4 “ISDN Network Termination Connector”
■ Section B.5 “Keyboard/Mouse Connector”
■ Section B.6 “SCSI Connector (External)”
■ Section B.7 “Serial Connector”
■ Section B.8 “Parallel Connector”
■ Section B.9 “13W3 Video Connector”
■ Section B.10 “Audio Ports and Audio Module”
■ Section B.12 “SCSI Connector (Internal)”
■ Section B.13 “Diskette Drive Connector (Internal)”
■ Section B.14 “SBus Connector (Internal)”
■ Section B.15 “Power Connector (Internal)”
