Chapter 12 Illustrated Parts Breakdown 12-5
Note – Although the part numbers are correct as of the publication date of this
document, they are subject to change. Consult your authorized Sun sales
representative or service provider to confirm part numbers before you order new or
replacement parts.
TABLE 12-1 Part Number List—Customer Replaceable Units
Item Description Sun Part No.
1 207-Mbyte Internal Disk Drive 370-1417
2 424-Mbyte Internal Disk Drive 370-1392
3 535-Mbyte Internal Disk 370-1424
4 1.0-Gbyte Internal Disk Drive 370-1546
5 Tri-density Floppy Drive 370-1419
6 70-Watt Power Supply 300-1101
7 System I/O Board 501-2269
8 Internal Speaker/Power LED Assembly 540-2233
9 Main Logic Board (0 Mbyte)—SPARCclassic 501-2262
10 Main Logic Board (0 Mbyte)—SPARCstation LX 501-2474
11 Main Logic Board (4 Mbyte)—SPARCclassic X 501-2079
12 Main Logic Board (8 Mbyte)—SPARCclassic X 501-2313
13 Upgrade (SPARCclassic X 4-Mbyte to Classic 16-Mbyte) 556-1774
14 Upgrade (SPARCclassic X 8-Mbyte to Classic 16-Mbyte) 556-1775
15 1-Mbyte DSIMM Module 501-2289
16 2-Mbyte DSIMM Module 501-2433
17 4-Mbyte DSIMM Module 501-1991
18 16-Mbyte DSIMM Module 501-2059
19 1-Mbyte VSIMM Module 501-2061
20 NVRAM/TOD 525-1203
21 NVRAM/TOD (SPARCclassic X) 525-1343
22 Diskette Drive Data Cable (Internal) 530-1643
23 Hard Drive Data Cable (Internal) 530-1678
24 13W3 Video Cable 530-1870
25 SCSI II Cable 530-1793
