12-1
CHAPTER
12
Illustrated Parts Breakdown
This chapter provides an illustrated parts breakdown (IPB) of the major parts that
comprise the SPARCclassic, SPARCclassic X, and SPARCstation LX systems, and a
list of customer replaceable units and their part numbers.
■ Section 12.1 “Illustrations of Selected CRUs”
■ Section 12.2 “Replacement Part List”
Note – Remember that diskette drive and hard drive parts do not apply to the
SPARCclassic X terminal.
12.1 Illustrations of Selected CRUs
FIGURE 12-1 through FIGURE 12-3 show exploded view illustrations of the
SPARCclassic/SPARCstation LX system unit.
