Chapter 9 Storage Devices 9-3
FIGURE 9-1 Hard Disk Drive in the Disk Drive Bracket
9.1.2 Preparing a Hard Drive for Installation
To prepare a hard drive for installation, you must first verify that the SCSI ID
jumpers on the drive controller board are set correctly. After you are satisfied that
the SCSI ID jumpers are correct, follow the directions later in the chapter for
installing the hard drive.
Hard drive
power cable
Hard disk drive
Drive screw holes
Pull tab
Diskette drive
Main logic
Keyboard soft
power-on cable
Cable
Power supply
UNIT TOP
data cable
power cable
management
guides
Pull tab
Disk drive bracket
without grommet
Disk drive bracket
with grommet
Hard drive
data cable
Disk drive
mounting bracket
Shoulder screw
