11-28 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
FIGURE 11-17 Removing and Replacing the Main Logic Board
System I/O board
Main logic board
Main logic board extractor lever
Speaker/power
LED assembly
UNIT BOTTOM
