7-1
CHAPTER
7
Internal Access
This chapter describes how to access the subassemblies inside the system unit, and
how to close the system unit after you have finished.
■ Section 7.1 “Disconnecting the External Cables”
■ Section 7.2 “Opening the System Unit”
■ Section 7.3 “Attaching the Wrist Strap”
■ Section 7.4 “Closing the System Unit”
■ Section 7.5 “Reconnecting the External Cables”
7.1 Disconnecting the External Cables
Detach all cables connected to the rear of the system unit. Take care to remember
where each cable attaches to the system unit.
Note – Do not disconnect the power cord from the system unit’s power receptacle.
The power cord should remain connected to a grounded power outlet.
To disconnect the SCSI cable:
1. Press in on both the finger clips of the connector that attaches the device to the
system unit.
2. Pull the connector off.
