B-10 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
FIGURE B-10 Audio Ports
B.11 Signals for the Audio Ports
B.11.1 Audio Line-Out Connector
FIGURE B-11 Audio Line-out Connector
This connector is used to connect the system audio output to a stereophonic
amplifier and external loudspeakers.
B.11.2 Audio Line-In Connector
FIGURE B-12 Audio Line-in Connector
TABLE B-10 Audio Ports
Line-Out Line-In
Left Channel Left Channel
Right Channel Right Channel
Return Return
