1-2 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
FIGURE 1-1 Front Panel of the SPARCclassic and SPARCstation LX System Units
The SPARCclassic X terminal chassis looks identical to the chassis shown above,
except that the components on the list below are either not available or are inactive,
and are consequently covered by connector covers:
■ Diskette drive slot
■ SCSI port
■ Audio port
■ Parallel port
Internally, the SPARCclassic X terminal differs from the basic SPARCclassic system
by the absence of the disk drive and diskette drive. The annotations to
FIGURE 1-2
and FIGURE 1-3 indicate the differences among the SPARCclassic system, the
SPARCstation LX system, and the SPARCclassic X terminal.
Diskette drive (optional)
System power LED
