12-4 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
FIGURE 12-3 Exploded View of the Disk Drive Mounting Bracket
12.2 Replacement Part List
TABLE 12-1 provides the part numbers for customer replaceable units, TABLE 12-2
provides part numbers for miscellaneous items, and TABLE 12-3 part numbers for
related documentation.
Screw holes
Diskette drive
Diskette drive power cable
Diskette drive data cable
Pull tab
Screw holes
Cable
Captive screw
Drive mounting bracket
management
guides
Drive select switch
(hidden from view)
