Connecting a Video Monitor
There are several different types of monitors and cabling. The color and grayscale
monitors use cables with 13W3 connectors. See Appendix C of the SPARCstation 10
Installation Guide for more specific information on monitors.
Connecting a Mouse
The optical mouse connects to one of two jacks in the back of the keyboard. The
mouse can be connected on either the left or right side to accommodate either
left-handed or right-handed users. Connect the mouse to the keyboard before you
connect the keyboard to the system unit.
Connecting a Keyboard
A cable connects the keyboard to the system unit. The keyboard port is located at the
left rear of the system unit (when viewed from the front). Connect the keyboard
cable on either the left or right side of the keyboard, then to the port on the back of
the system unit.
Turn On the Power
After turning off the power to replace a part, turning the power on again is relatively
simple.
Caution - This device is equipped with a three-wire grounded power cord. To
reduce the risk of electrical shock, always plug the power cord into a properly
grounded power outlet.
Caution - Before powering on your system, be sure to install the cover. It is not safe
to operate the SPARCstation 10 system without the top cover in place.
172 SPARCstation 10 Service Manual ♦ Revision A, July 1993
