System Placement Requirement
The SPARCstation 10 system unit has vents on its left and right panels for ventilation
and a slot on its right panel for diskettes. When you place the unit on a desktop,
make sure that objects do not block the vents on either side of the unit.
Caution - Do not block the vents on the side of the system unit.
Allow at least 3 inches (76 millimeters) of unobstructed space on either side of the
system unit.
Physical Dimensions
Table A–3 lists the physical specifications for the system unit, the keyboard, and the
optical mouse.
TABLE A–3 Physical Specifications
Component Height Width Depth Net Weight
System Unit 2.8 in (71 mm) 16 in (409 mm) 16.0 in (409 mm) 25 lb (11 kg)
Keyboard, Type
5
1.7 in (44 mm) 20.1 in (510 mm) 7.2 in (182 mm) 3.5 lb (1.6 kg)
Mouse 2.0 in (50 mm) 4.0 in (100 mm) 3.0 in (80 mm) 3 lb (14 kg)
System Specifications 177
