CHAPTER 10
SBus Cards
If you are removing a defective SBus card, install the replacement card in the same
slot. Refer to the documentation shipped with the SBus card for installation
information.
Tools Needed
To remove and install an SBus card you will need the following tools and materials:
4
Phillips screwdriver (size #1)
4
Phillips screwdriver (size #2)
4
Card extractor
4
Wrist strap
4
Antistatic surface
Removing an SBus Card
1. Power off the system and disconnect the expansion units.
Refer to “Halting the System” on page 29 in Chapter 4.
2. Make sure that the green LED on the front of the chassis is not lit.
3. Leave the power cord connected to the system and to the wall outlet.
105
