4
Video Frame Capture Card
This card occupies one SBus slot. This card takes video input and displays it on color
or monochrome monitors.
4
SBus Printer Card
This card occupies one SBus slot. This card connects the system to printing, plotting
and scanning devices.
4
1-Bit Analog Frame Buffer Card
This card occupies one SBus slot. It controls the video output from the system to a
monochrome monitor.
Monitors, Keyboard, and Mouse
Each system uses a keyboard, an optical mouse, and one of several types of video
monitors. Table 1–2 lists the monitors supported.
TABLE 1–2 Video Monitor Types
Monitor Type Voltage
16-inch color monitor (407 mm) 115V
16-inch color monitor (407 mm) 240V
19-inch standard grayscale monitor (483 mm) 90-240V
19-inch high-resolution monochrome monitor (483 mm) 115V
19-inch high-resolution monochrome monitor (483 mm) 240V
17-inch grayscale (432 mm) 90-240V
19-inch color monitor (483 mm) 115V
19-inch color monitor (483 mm) 240V
16-inch color overscan monitor (407 mm) 90-240V
19-inch color overscan monitor (483 mm) 90-240V
17-inch grayscale overscan monitor (432 mm) 90-240V
19-inch grayscale overscan monitor (483 mm) 90-240V
System Overview 7
