Chapter 3 Server Diagnostics 3-23
95 100
MB/CMP0/T_BCORE OK 45 -10 -5 0 85
95 100
IOBD/IOB/TCORE OK 41 -10 -5 0 95
100 105
IOBD/T_AMB OK 30 -10 -5 0 45
50 55
--------------------------------------------------------
System Indicator Status:
--------------------------------------------------------
SYS/LOCATE SYS/SERVICE SYS/ACT
OFF ON ON
--------------------------------------------------------
SYS/REAR_FAULT SYS/TEMP_FAULT SYS/TOP_FAN_FAULT
OFF OFF OFF
--------------------------------------------------------
--------------------------------------------
System Disks:
--------------------------------------------
Disk Status Service OK2RM
--------------------------------------------
HDD0 OK OFF OFF
HDD1 OK OFF OFF
HDD2 OK OFF OFF
HDD3 OK OFF OFF
---------------------------------------------------
Fans Status:
---------------------------------------------------
Fans (Speeds Revolution Per Minute):
Sensor Status Speed Warn Low
----------------------------------------------------------
FT0/FM0 OK 3618 -- 1920
FT0/FM1 OK 3437 -- 1920
FT0/FM2 OK 3556 -- 1920
FT2 OK 2578 -- 1900
----------------------------------------------------------
------------------------------------------------------------------------------
--
Voltage sensors (in Volts):
------------------------------------------------------------------------------
--
Sensor Status Voltage LowSoft LowWarn HighWarn HighSoft
------------------------------------------------------------------------------
--
MB/V_+1V5 OK 1.48 1.36 1.39 1.60 1.63
MB/V_VMEML OK 1.78 1.69 1.72 1.87 1.90
MB/V_VMEMR OK 1.78 1.69 1.72 1.87 1.90
MB/V_VTTL OK 0.87 0.84 0.86 0.93 0.95
MB/V_VTTR OK 0.87 0.84 0.86 0.93 0.95
