3-24 Sun Fire T2000 Server Service Manual • July 2007
Note – Some environmental information might not be available when the server is
in standby mode.
MB/V_+3V3STBY OK 3.33 3.13 3.16 3.53 3.59
MB/V_VCORE OK 1.30 1.20 1.24 1.36 1.39
IOBD/V_+1V5 OK 1.48 1.27 1.35 1.65 1.72
IOBD/V_+1V8 OK 1.78 1.53 1.62 1.98 2.07
IOBD/V_+3V3MAIN OK 3.38 2.80 2.97 3.63 3.79
IOBD/V_+3V3STBY OK 3.33 2.80 2.97 3.63 3.79
IOBD/V_+1V OK 1.11 0.93 0.99 1.21 1.26
IOBD/V_+1V2 OK 1.17 1.02 1.08 1.32 1.38
IOBD/V_+5V OK 5.09 4.25 4.50 5.50 5.75
IOBD/V_-12V OK -12.11 -13.80 -13.20 -10.80 -10.20
IOBD/V_+12V OK 12.18 10.20 10.80 13.20 13.80
SC/BAT/V_BAT OK 3.03 -- 2.69 -- --
-----------------------------------------------------------
System Load (in amps):
-----------------------------------------------------------
Sensor Status Load Warn Shutdown
-----------------------------------------------------------
MB/I_VCORE OK 25.280 80.000 88.000
MB/I_VMEML OK 4.680 60.000 66.000
MB/I_VMEMR OK 4.680 60.000 66.000
-----------------------------------------------------------
----------------------
Current sensors:
----------------------
Sensor Status
----------------------
IOBD/I_USB0 OK
IOBD/I_USB1 OK
FIOBD/I_USB OK
------------------------------------------------------------------------------
Power Supplies:
------------------------------------------------------------------------------
Supply Status Underspeed Overtemp Overvolt Undervolt
Overcurrent
------------------------------------------------------------------------------
PS0 OK OFF OFF OFF OFF OFF
PS1 OK OFF OFF OFF OFF OFF
sc>
