Sun Microsystems Sun SPARC Enterprise M4000 User Manual

Chapter 2 Setting Up XSCF 2-107
FIGURE 2-7 XSB Configuration Diagram (Quad-XSB) (In the High-End Servers)
FIGURE 2-8 shows Uni-XSB hardware configuration diagrams in an entry-level server.
The PSB type is fixed to Uni-XSB. In the entry-level server, the number of domains is
one, and the domain fully uses the resources in the PSB
FIGURE 2-8 XSB Configuration Diagram (Uni-XSB) (In the Entry-Level Server)
XSB#xx-3
XSB#xx-2
XSB#xx-1
XSB#xx-0
Memory
I/O device
Memory
Memory
Memory
I/O device
I/O device
I/O device
IOU#nCMU#n
When PSB#n is Quad-XSB type
