Suzuki GSF650A - Handlebar Construction (GSF650;S;A;SAK7)

Steering / Handlebar: 6B-2
Handlebar Construction (GSF650/S/A/SAK7)
B817H26206002
(a) (a)
(a)
“B”
(a)
“B”
“a”
“a”
“a”
“A”
1
“A”
2
“A”
3
“A”
(b)
FWD
I718H1620040-01
1. Clutch master cylinder “A”: Punch mark : 10 N⋅m (1.0 kgf-m, 7.0 lb-ft)
2. Front brake master cylinder “B”: UP mark : 23 N⋅m (2.3 kgf-m, 16.5 lb-ft)
3. Handlebar holder “a”: Clearance
